Fork
Orbea Terra ICR, full carbon, 1-1/8″ – 1,5″ tappered head tube compatible, Thru axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready.
Frame
Orbea Terra Hydro disc, hydroformed triple butted aluminium, HS 1,5″, PF, Thru Axle 12mm x 142mm rear, thread M12x2 P1, DT internal cable routing, 27,2mm seat tube
Headset
FSA 1-1/2″ Integrated Aluminium Cup
Crankset
Shimano Cues U6030 34x50T
Shifters
Shimano U6030
Cassette
Shimano CS-LG300 11-39t 10-Speed
Rear derailleur
Shimano Cues U6020 SGS Shadow
Front derailleur
Shimano Cues U6030
Chain
Shimano LG500
Handlebar
OC Riser Handlebar GR31-R
Stem
OC Road Performance 23, -5º
Brakes
Shimano RS405 Hydraulic Disc
Brakes Configuration
N/A
Wheels
Alloy, Tubeless, 700c, 21c
Tyres
Vittoria Terreno T50 mixed Gravel Sport Rigid 700x45c
Front Wheel Axle
Orbea Thru Axle 12x100mm M12xP1 Hollow
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 20mm
Saddle
Fizik Terra Argo X7 Aluminium Rail 140mm
Mudguard
N/A
Handlebar Tape
Orbea Eva
