Fork
Orbea Terra ICR, full carbon, 1-1/8″ – 1,5″ tappered head tube compatible, Thru axle 12x100mm, thread M12xP1, MMS multi mount system, fender ready.
Frame
Orbea Terra Hydro disc, hydroformed triple butted aluminium, HS 1,5″, PF, Thru Axle 12mm x 142mm rear, thread M12x2 P1, DT internal cable routing, 27,2mm seat tube
Headset
FSA 1-1/2″ Integrated Aluminium Cup
Crankset
Shimano GRX RX610 30x46T
Shifters
Shimano GRX RX610
Cassette
Shimano HG710 11-36T 12S
Rear derailleur
Shimano GRX RX820
Front derailleur
Shimano GRX RX820
Chain
Shimano M6100
Handlebar
OC Riser Handlebar GR31-R
Stem
OC Road Performance 23, -5º
Brakes
Shimano RX410 Hydraulic disc
Brakes Configuration
N/A
Wheels
Alloy, Tubeless, 700c, 21c
Tyres
Vittoria Terreno T50 mixed Gravel Sport Rigid 700x45c
Front Wheel Axle
Orbea Thru Axle 12x100mm M12xP1 Hollow
Rear Wheel Axle
Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded
Seatpost
SP 0.2 Carbon, 27.2mm, Setback 20mm
Saddle
Fizik Terra Argo X7 Aluminium Rail 140mm
Mudguard
N/A
Handlebar Tape
Orbea Eva
