FRAME Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700×35 max tyre, BB386 EVO, Mahle X20 AMC plug.
FORK Gain OMR carbon fork, 700×35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
HEADSET FSA 1-1/2″ Integrated Aluminium Cup
BATTERY Mahle iX350 36V 353Wh
RANGE EXTENDER Optional
MOTOR Mahle motor hub X20, ALC
DISPLAY Mahle Pulsar One monochrome ANT+ LEV
CHARGER Mahle Active Charger up to 4A
REMTOE Mahle ONE Head Unit (BT/ANT+)
REMOTE 2 Mahle Handlebar Dual eShifter
CRANKSET Shimano Ultegra R8100 34x50t
SHIFTERS Shimano ST-8170
CASSETTE Shimano Ultegra R8100 11-30t 12-Speed
REAR DERAILLEUR Shimano Ultegra Di2 R8150
FRON DERAILLEUR Shimano Ultegra Di2 R8150
CHAIN Shimano M8100
HANDLEBAR OC Road Performance RP11-R Carbon, Rise 15, Reach 70, Drop 125
STEM OC Road Performance RP10, -8º
BRAKES Shimano R8170 Hydraulic Disc
WHEELS Carbon 42, Tubeless, 21c
TYRES Pirelli P ZERO™ Race X SmartEVO TLR 700x30c
FRONT WHEEL AXLE Orbea Thru Axle 12x100mm M12x2 P1 Lite
REAR WHEEL AXLE Orbea Thru Axle 12x142mm M12x2 P1 Lite
SEATPOST OC Performance XP10-S Carbon, 27.2mm, Setback 20
SADDLE Fizik Vento Antares R3 Kium Rail 140mm
FRONT LIGHT Front position light, on display holder, COB Led, On/Off, 60 Lumen, ECE50.
REAR LIGHT Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
HANDLEBAR TAPE Orbea Anti-Slippery/Shock Proof
